Many readers in Patna, Bihta and nearby districts are searching for the Bihta Airport master plan, its layout plan, terminal drawing and official project documents. This guide explains which authentic documents are publicly available, what they show, and how to identify an official plan from a tender drawing, news graphic or conceptual rendering.
Document availability checked on 13 October 2026. At the time of checking, a standalone official “Bihta Airport Master Plan” PDF could not be verified as publicly available. However, official Cabinet approval releases and an Airports Authority of India tender page provide reliable information about the project’s approved scope and layout.
Is the Official Bihta Airport Master Plan PDF Available?
No standalone official Bihta Airport master-plan PDF was found in a publicly accessible government source during this check. Therefore, readers should be careful with social-media posts, property websites or blogs that describe an unofficial image as the “approved master plan”.
The closest official material is a 2019 presentation submitted by the Airports Authority of India to the Airports Economic Regulatory Authority of India. It contains a slide titled “Bihta Airport Master Plan”, but the document is mainly a tariff consultation presentation for Patna’s Jay Prakash Narayan International Airport. It should not be treated as the final, standalone master plan for the Bihta civil enclave.
For the current civil-enclave project, the most useful verified documents are the Cabinet approval releases and the Airports Authority of India EPC tender page. These documents confirm the project scope, terminal capacity, apron, taxiways and several landside facilities, but they are not the same thing as a complete airport master plan.
Where to Find Bihta Airport Project Documents
The following official sources are the best starting points for authentic Bihta Airport information.
- Cabinet approval release: This official release records the Cabinet Committee on Economic Affairs approval, estimated cost of ₹1,413 crore, terminal area, passenger capacity, apron and taxiway details.
- Cabinet project release: This confirms that the Bihta civil enclave was approved on 16 August 2024 and repeats the main project components.
- Airports Authority of India EPC tender page: This is the most detailed official technical source. It describes the terminal, utility building, elevated road, parking, basement, passenger facilities, utilities and drainage, and states that layout plans and drawings were attached to the tender document.
- Airports Economic Regulatory Authority presentation: This PDF includes a Bihta Airport master-plan slide, but it is an older 2019 tariff-related presentation rather than a current approved master-plan document.
- Official Bihar Air feature document: This describes the civil enclave as a major hub west of Patna and mentions its ₹1,413 crore investment and 50 lakh passenger capacity.
Bihta Airport Layout Plan: What Is Documented?
The available official documents do not provide one simple public page that shows the complete final airport layout. But together, the Cabinet approval and Airports Authority of India tender documents describe the main parts of the planned civil enclave.
Passenger terminal
The approved project includes a new integrated terminal building of 66,000 square metres. It is designed for 3,000 peak-hour passengers and 50 lakh passengers annually in the initial stage. The government has also stated that capacity can be expanded by another 50 lakh passengers, taking the ultimate capacity to one crore passengers per year.
Apron and aircraft parking
The project includes an apron with 10 parking bays suitable for A-321, B-737-800 and A-320 type aircraft. The same approval release mentions two link taxiways connecting the apron area to the airfield.
Roads, parking and landside facilities
The tender describes an elevated vehicular road with a roof covering seven lanes for drop-off in front of the terminal on the city side. It also includes surface parking for 10 buses, separate car and scooter parking for airport and airline staff, a basement, surface roads, landscaping, drainage, rainwater harvesting and utility buildings.
Utilities and support infrastructure
The tender scope includes water supply, water treatment, sewage treatment, air-conditioning plant rooms, backup generators, sub-station facilities, horticulture and related services. These are part of the civil-enclave construction scope, not necessarily a separate publicly released utility master plan.
Bihta Airport Terminal Building Plan
The terminal is the central part of the Bihta civil enclave. The tender describes a centrally air-conditioned integrated terminal with a basement, designed to meet GRIHA 5 green-building standards and to be carbon neutral at the operational-emissions level.
The tender also describes separate functional areas:
- Departure concourse, check-in area, baggage conveyors, airline offices and facilitation counters.
- Security hold area with seating, frisking platforms, hand-baggage inspection tables, child-care room and smoking area.
- Arrival and baggage-claim areas.
- Common concourse with snack counters, travel-related shops, pharmacy, airline offices, ticket counters, ATMs, first-aid room and airport management offices.
- Retail and food-and-beverage areas along passenger movement routes.
- VIP and CIP lounges.
These details come from the tender’s project description. They show the intended terminal planning and passenger facilities, but they should not be confused with a final as-built terminal drawing or a public “terminal layout PDF”.
Bihta Airport Runway and Apron Layout
The verified Cabinet approval states that the project includes an apron for 10 parking bays and two link taxiways. These are confirmed components of the approved civil-enclave scope.
However, this research did not find a current official public document that gives a complete, final runway layout drawing for the Bihta civil enclave. Readers should therefore avoid relying on low-resolution maps or unofficial images for runway length, orientation or exact alignment.
The older regulatory presentation refers to land acquisition for extension of the runway to accommodate Code E aircraft, but this is historical project-related information from 2019 and should not be treated as the current approved runway design.
What Does the Bihta Airport Project Report Say?
There is no verified public standalone “Bihta Airport project report PDF” identified in this research. Still, official government releases provide the key approved project facts.
| Project detail | Verified information |
|---|---|
| Project name | Development of New Civil Enclave at Bihta, Patna, Bihar |
| Approving authority | Cabinet Committee on Economic Affairs |
| Implementing authority | Airports Authority of India |
| Approved cost | ₹1,413 crore |
| Approval date | 16 August 2024 |
| Terminal area | 66,000 square metres |
| Initial capacity | 3,000 peak-hour passengers; 50 lakh passengers annually |
| Future capacity | Expandable to one crore passengers annually |
| Airfield components | Apron with 10 parking bays and two link taxiways |
Difference Between a Master Plan, Tender Drawing and Airport Map
These terms are often used loosely online. Knowing the difference helps readers avoid treating an illustration as an approved government plan.
| Document type | What it means | Can it be treated as final? |
|---|---|---|
| Official master plan | A comprehensive planning document showing long-term airport development, land use, phases and major facilities. | Only if the issuing authority clearly states that it is approved and current. |
| Official project report or approved scope | An official document explaining the approved project, cost, capacity and main components. | It confirms project scope, but may not contain every detailed layout drawing. |
| Tender drawing or technical layout | A drawing attached to a construction tender for a specific work package or project stage. | No. It guides the contractor for that tender and may change through construction processes. |
| Conceptual design or rendering | An image showing how a terminal or airport may look. | No. It is illustrative and does not prove final approval or construction details. |
| News graphic or unofficial map | A map or graphic prepared by a media house, blogger or property website. | No. Use it only as background, not as an official planning document. |
How to Download or Access Official Documents
Readers looking for authentic documents can follow these steps:
- Open the official Airports Authority of India tender page for the Bihta civil enclave.
- Read the project title, scope and tender details carefully.
- Look for attached documents, drawings or tender-related files on the official page or the government procurement portal linked from it.
- Check the document title, issuing authority, date and whether it is marked as a draft, tender document, drawing or approved plan.
- Use the official download option provided on the source page. Do not depend on third-party re-uploads.
- For project approval and capacity details, use the official Cabinet approval release.
How to Check Whether a Bihta Airport Map Is Genuine
Before sharing or trusting a Bihta Airport map, check these points:
- Issuing authority: Genuine planning documents normally come from the Airports Authority of India, Ministry of Civil Aviation, Press Information Bureau, Airports Economic Regulatory Authority or another official government body.
- Project name: The document should clearly mention “Bihta”, “New Civil Enclave at Bihta” or the exact tender/project title.
- Date and revision: An old drawing may not reflect the latest approved scope.
- Document label: Look for words such as “conceptual”, “tender”, “draft”, “indicative”, “approved” or “final”.
- Source URL: Prefer an official government website.
- Purpose: A rendering may show design intent, but it does not prove that the exact layout has been constructed or approved.
Frequently Asked Questions
Is the Bihta Airport master plan PDF available online?
A standalone official Bihta Airport master-plan PDF was not verified as publicly available during this check. The closest official item is a 2019 regulatory presentation containing a Bihta master-plan slide, but it is not a standalone approved master plan.
Where can I find the official Bihta Airport layout?
The best official source is the Airports Authority of India EPC tender page. It states that layout plans and drawings were attached to the tender document and describes the terminal, roads, parking, utilities and other facilities.
Is a tender drawing the same as an approved master plan?
No. A tender drawing is prepared for a particular construction contract or work package. An approved master plan is a broader planning document. A tender drawing may be official, but it is not automatically the final airport master plan.
Where can I find the Bihta Airport terminal plan?
The official tender page describes the terminal’s departure, arrival, security hold, concourse, retail, food-and-beverage and support areas. It also says that drawings were attached to the tender.
Are the runway and apron layout publicly available?
The apron and two link taxiways are confirmed in the Cabinet approval release. A complete current public runway-layout drawing was not verified in this research.
Which authority is responsible for the project?
The Airports Authority of India is the implementing authority for the new civil enclave. The project was approved by the Cabinet Committee on Economic Affairs, and the Bihta airbase is associated with the Indian Air Force.
How can I verify an airport project PDF?
Check the issuing authority, document title, date, project name and whether the file is hosted on an official government website. Avoid relying on screenshots, social-media forwards or property-blog maps.
Where can I find the latest official project documents?
Check the Airports Authority of India website, Ministry of Civil Aviation, Press Information Bureau and official government procurement portals. The tender page and Cabinet releases are the strongest verified starting points.
Final Summary
The Bihta Airport master plan is a subject where readers must separate verified official documents from unofficial maps and renderings. As of 13 October 2026, no standalone public official master-plan PDF for Bihta Airport was verified.
The most reliable official documents are the Cabinet approval releases and the Airports Authority of India EPC tender page. Together, they confirm a ₹1,413 crore civil enclave, a 66,000 square metre terminal, 3,000 peak-hour passenger capacity, 50 lakh annual passenger capacity, 10 apron bays and two link taxiways.
For authentic updates, always begin with official government sources rather than unofficial Bihta Airport maps or property-related graphics.
